Designed seismic resistant structure zone III using Fe 500 steel TMT bars
Using chamber bricks for all walls
200mm outer wall and 100mm block for the internal partition wall
Floor to floor height will be maintained at 3.05m
Main door will be polished wooden door of 7 feet height with Godrej or equivalent locks, tower bolts, door viewer, door stopper etc.
Bedroom Flush doors of 7 feet height with Godrej or equivalent locks, thumb turn with keys, door stopper, etc.
FRP doors of 7 feet height with thumb turn is used for Bathroom
All windows will be UPVC door and panel with plain glass and MS grills on inner side wherever applicable
Ventilators will have Aluminium frame with suitable louvered glass panels
Internal wall in the living, dining, bedrooms, kitchen & lobby will be finished with 1 coat of primer, 2 coats of putty & emulsion
Ceiling will be finished with 2 coats of putty and emulsion
Exterior faces of the building will be finished with 1 coat of primer & 2 coats of emulsion paint
Utility & bathrooms will be finished with 1 coat of primer & 2 coats of emulsion
Bathroom walls will be finished with glazed ceramic tiles up to 7 feet from finished floor level
Utility walls to be finished with glazed ceramic tiles up to 4 feet from finished floor level
Living, kitchen & bedrooms will have 600 X 600mm vitrified tile flooring
Bathroom will have 300 x 300mm ceramic tile of matte finish
Staircase will be tile flooring
Platform will be done with granite slab 600mm wide at a height of 800mm from the floor level and will be provided with stainless steel sink with drain board
Dado tiles of up to 600mm from the granite slab
Exhaust point and RO point will be provided
CP fittings will be Parryware / Hindware or equivalent
Wall mounted basin from Parryware / Hindware or equivalent will be provided in all bathrooms
Floor mounted W/C with cistern from Parryware / Hindware or equivalent will be provided in all bathrooms
Sanitary fittings will be Parryware / Hindware or equivalent
Wall mixer from Parryware / Hindware or equivalent in all bathrooms
CP fittings will be Parryware / Hindware or equivalent
Exhaust point will be provided
Geyser point will be provided
Finolex or equivalent cables and wiring
Switches and sockets will be Anchor Roma or equivalent
Telephone and DTH points will be provided in master bedroom and living room
Split air conditioner point in master bedroom and provision will be given in all other bedrooms
Modular plate switches, MCB and ELCB(Earth leakage circuit breaker) system
EB connection will proivided
UHT , OHT and Septic tank will provided for suitable capacity and size for residential building
